| Brand Name : | Dowis |
| Model Number : | EE16 EE Series |
| Certification : | CE, UL, ISO,16949,RoHs |
| Payment Terms : | T/T, L/C |
| Delivery Time : | 3-4weeks |
EE1614 High-Frequency Transformer Manufacturer Customized EE Series DW4418
Features:
1. Custom designs available
2. High efficiency of over 95%
3. High Power Electronic Transformer
4. High isolation strength
5. Lower profile and weight
6. high power density
7. High-temperature resistant
8. Operating temperature : -40°C to +125°C
9. Power range 10w-10kw
Application:
1. VCRS, Copy machine , Audio equipment , Game machines
2. TV sets, Microcomputer equipment, printers, Terminals
3. communications control equipment
4. Switching power supply, chargers, alarm system
5. UPS, VCD/DVD players, audio and visual equipment
6. OA machines, inverters, chargers, alarm system
Transformer TYPE | PRODUCTS |
PQ | PQ2020 PQ2016 PQ2625 PQ3230 PQ4040 PQ5050 |
EI | EI19 EI16 EI28 EI40 EI33 EI20 EI25 EI26 EI30 |
EE | EE16 EE18 EE20 EE25 EE55 EE19 EE13 EE22 EE28 |
EF | EF35 EF33 EF16 EF18 EF25 EF26 EF32 EF30 EF28 |
ERL | ERL28 ERL35 ERL39 ERL44 ERL49 ERL55 ERL59 |
ETD | ETD18 ETD29 ETD34 ETD39 ETD44 ETD49 ETD54 ETD59 |
EFD | EFD29 EFD15 EFD20 EFD25 EFD33 EFD30 EFD28 EFD26 |
RM | RM-4 RM-5 RM-6 RM-7 RM-8 RM-12 RM-10 RM-14 RM-16 |
1. Drawing (Unit:mm)
2. Environmental Conditions
3. Electrical Specification
二,
| Item | Unit | Test Lead | Test Condition | MIN | NOR | MAX |
| Inductance Value | uH | 6-7 | 100KHz,0.3V, Ser | 100 | 110 | 120 |
| Leakage Inductance | uH | 6-7 | 100KHz,0.3V, Ser (Other Winding Short Circuit) | / | / | 10 |
| Q Value | / | 6-7 | 100KHz,0.3V, Ser | 50 | / | / |
| Dielectric Strength | mA | N1,N2－N3 | 1800Vac,60s | / | / | 1 |
| mA | N1,N2－Core | 1500Vac,60s | / | / | 1 | |
| mA | N3—Core | 1500Vac,60s | / | / | 1 | |
| Direct Current Resistance | mΩ | 4-5 | 25℃ | / | / | 85 |
| mΩ | 6-7 | 25℃ | / | / | 90 | |
| mΩ | 8-9 | 25℃ | / | / | 1050 | |
| Insulation Resistance | MΩ | Np-Ns | 500Vdc | 100 | / | / |
