    66uH PQ32 Small PQ Transformer New Energy Magnetics

    Ask Lasest Price
    Brand Name : Dowis
    Model Number : PQ32 series
    Certification : CE, UL, ISO,16949
    Price : Negotiable
    Payment Terms : L/C, T/T
    Delivery Time : 3-4weeks
    • Product Details
    • Company Profile

    66uH PQ32 Small PQ Transformer New Energy Magnetics

    PQ32 New Energy Magnetics Transformer DW4986


    Key Properties:

    1. High precision, wide linearity range for output current

    2. High potential voltage (4000Vac for 1min)

    3. Outstading stability

    4. Low profile elegant looking

    5. Directly installed to PCB


    Main Application:

    · Electronic energy meter

    · Power transducer

    · Precision power meter and other power & energy monitoring devices

    · Over current protection circuit of motor and other electrical appliances


    1. Electrical Specification

    ItemUnitTest LeadTest ConditionMINNORMAX
    Inductance ValueµH1-2100KHz,0.3V, Ser626670
    µH7-8100KHz,0.3V, Ser5.766.3
    Leakage InductanceµH1-2

    100KHz,0.3V, Ser

    (N2 Winding Circus)

    //1.5
    Q Value/1-2100KHz,0.3V, Ser120//
    /7-8100KHz,0.3V, Ser70//
    Dielectric
    Strength
    mAN1—N2,N33750Vac,60s//1
    mAN1—Core1000Vac,60s//1
    mAN2,N3—Core2000Vac,60s//1
    mACoil-Core2500Vac,60s//1
    Direct Current Resistanc1-225℃//3.5
    3-425℃//2.5
    5-625℃//12
    7-825℃//6
    Insulation ResistanceNp-Ns500Vdc100//

    2. Drawing (Unit:mm)




    3. Environmental Conditions

    • Storage Temperature: -40--85˚C;
    • Enviornmental Temperature: -40--85˚C;
    • Operating Temperature: 130˚C MAX;
    • Relative Humidity: 5%-95%;
    • Long Term Durability Test.
